Where is the part number on a transfer case?
John Peck Where is the part number on a transfer case?
The part number is either stamped onto the transfer box or on a sticker. Below we will show you an example of where you can find the part number.
How do I know if I have a Dana transfer case?
The Dana 18, as it is commonly referred, is easily identified as it has both front and rear outputs offset to the passenger side of the Jeep. It also has 2 shifters one for high and low, the other to engage/disengage 4-wheel drive. There are 5 different varieties of the Dana 18 transfer case.
How do I know if I have a 203 transfer case?
The NP203 is identified by several features: 1. The transfer case is made up of 4 sections bolted together, a range box (the gear reduction we use for the Doubler kit), the chain case which houses the chain drive to the front driveshaft output, the differential housing, and the output housing.
How do I identify a new process transfer case?
New Process/New Venture transfer cases are easy to identify. Early models have a rectangular ID plate screwed to the back of the case; newer ones have a round red/silver/black tag on their backsides. BorgWarner models have an assembly tag secured by one of the housing’s bolts.
What vehicles use a np231d transfer case?
The NP231 transfer case found in many late-model Jeep, Dodge, and GM vehicles has a fairly good reputation for a chaindriven, aluminum-cased unit, but improper towing procedures can cause it to explode, and some of the internals are iffy for big tires and lots of torque.
What is RPO code NP8?
Description. RPO “NP8” (white tag with option codes in glove box) indicates auto electronic shift. Automatic Electronic Shift (4 Wheel High, Low And Auto)
How do I know if I have a Dana 20 transfer case?
The Dana 20 is a cast iron transfer case, having a passenger-side front output and a centered rear output. It has the same “Texas” front mounting input flange as does the Dana 18. Markings on the Dana 20 can vary, but most start with a C18-15-24… Some confuse them for a large case Dana 18 because of this.
How much does a 203 transfer case weigh?
NP203 Specs
| Manufacturer: | New Process Gear |
|---|---|
| Pass/Driver Drop: | Driver and passenger side drops |
| Weight: | ~ 200 lbs |
| Fluid Type*: | 10w-30 or straight 30w motor oil |
| Identification: | ID tag located above front output shaft. |
How do I identify a NP208 transfer case?
- NP208.
- Identify: Aluminum case; driver-side front output.
- Low-Range: 2.62.
- Lubricant: ATF.
- Notes: It looks similar to the NP207 but has a 23-spline input shaft. Found in ’80s Cherokees and pickups, it is the heart of the Command-Trac system. Dodge and Jeep versions have bolt-on yokes; others have a slip-yoke.
What is the difference between NP231 and np242?
The addition of a center differential is the main difference between the NP 242 and the NP 231 or Command Trac transfer case. Without a differential, the 231 transfer case offers only part time four wheel drive mode.
What does NP231 mean?
It means you should only use the 4wd on surfaces where it can get wheel slipage.
