What is OH6 pump?
Emily Wilson What is OH6 pump?
Sundyne API 610, 11th Edition OH6 Integrally Gear Driven Pumps are engineered for critical high-head, low-flow, heavy-duty services required by process and rotating equipment engineers within the hydrocarbon, chemical, petrochemical, power generation, gas production, and specialty processing industries.
How do I start my Sundyne pump?
Sundyne pump start-up procedure Open the seal vent port, either port #5 or #6 (please check from vendor manual). Open the pump discharge valve 25%. Start the main pump motor and observe the flow rate and discharge pressure. Adjust the discharge valve for the pump operation with the recommended flow limits.
What is sealless pump?
A sealless mag drive pump is a conventional centrifugal pump without the dynamic seal that would normally be used to seal the pump shaft. This dynamic seal is replaced by a static containment shell to form a completely sealed liquid end or pressure boundary.
What is BB5 pump?
The BB5 type, KBDS and KBDD pumps are double casing, radially split multistage between bearing pumps conforming to API 610 requirements. These pumps are suitable for wide applications in high pressure fluid handling in oil refineries and petrochemical industry.
What is overhung pump?
Overhung Impeller Type: The impeller is mounted on the end of a shaft which is “overhung” from its bearing supports. – Close Coupled pumps where the impeller is mounted directly on the motor shaft – Separately coupled or frame mounted where the impeller is mounted on a separate pump shaft supported by its own bearings.
What is a canned pump?
A CANNED MOTOR PUMP IS COMPOSED OF: A TRADITIONAL CENTRIFUGAL HYDRAULIC & A SPECIAL SQUIRREL CAGE MOTOR CONNECTED IN A ONE PIECE ASSEMBLY. The pump liquid circulates through the rotor chamber, cooling the motor, and lubricating the slide bearings that support the rotor.
What is api685?
This API standard specifies the minimum requirements for sealless centrifugal pumps for use in petroleum, heavy duty petrochemical and gas industry services. This standard is applicable to single stage overhung pumps of two classifications, Magnetic Drive Pumps (MDP) and Canned Motor Pumps (CMP).
What is a BB2 pump?
The PWR-D BB2 is a radial split between bearings pump offered in either one or two stages. This center line mounted pump has two heads to allow disassembly without disturbing the driver. It is designed for reliable operation in heavy-duty elevated temperature process services.
What is API pump?
A type of pump designed to meet the American Petroleum Institute (API) 610 standard for pumps handling hydrocarbons. They come in many different forms and may employ a number of pumping mechanisms. The API 610 standard is limited to centrifugal pumps, but API process pumps come in many different configurations.
What is overhung impeller pump?
A centrifugal pump whose impeller is mounted on the end of a shaft that overhangs its bearings.
What is an API pump?
What is an API process pump? A type of pump designed to meet the American Petroleum Institute (API) 610 standard for pumps handling hydrocarbons. They may be end suction pumps, horizontal split case pumps, multistage pumps, vertical inline pumps, or vertical turbine pumps.
