How do I enable ping in Juniper?

Solution

1. Log into the web console of the Juniper.
2. Navigate to Security > Zones/Screen > Select the ‘Untrust’ Zone > Edit > Host inbound traffic – Interface > Under Interface services add in ‘ping’ > OK. Note: To allow pinging of the inside interface select the trusted zone.
3. Then to save the change click Action > Commit.

How do I find my interface configuration in Juniper?

To display the current configuration for a Juniper Networks device, use the show command in configuration mode. This command displays the configuration at the current hierarchy level or at the specified level.

How do I set an IP address on a Juniper router?

Solution:

1. Use the command “family inet address” to configure a management IP address on the interface. set interfaces me0 unit 0 family inet address 10.93.15.246/21.
2. Configure a static route with the next hop to the management network default gateway set routing-options static route 0.0.0.0/0 next-hop 10.93.15.1/21.

How do I reset my juniper ssg5?

Push and HOLD pinhole with thin wire. The Status LED will turn to a “blinking amber’. Keep holding, and when it turns to ‘blinking green’, immediately release the pinhole.

How do I configure my Juniper router?

To configure the software:

1. Verify that the router is powered on.
2. Log in as the “root” user. There is no password.
3. Start the CLI.
4. Enter configuration mode.
5. Configure the name of the router.
6. Create a management console user account.
7. Set the user account class to super-user.
8. Configure the router’s domain name.

How do I enable interface in Juniper?

Enable/Disable Interface in Juniper

1. [email protected]# set interfaces ge-0/0/1.0 disable << This is cisco equivalent of “shutdown” – To Juniper enable interface:
2. [email protected]# delete interfaces ge-0/0/1.0 disable << This is cisco equivalent of “no shutdown” Verification:
3. [email protected]#show ge-0/0/1.0.

How do I add a secondary IP address to Juniper?

Knowledge Base

1. Open the WebUI.
2. From the ScreenOS options menu, click Network, and then click Interfaces.
3. From the desired interface that you want to add the secondary IP address, click Edit.
4. From the Edit page, click Secondary IP.
5. In the IP Address/Netmask text boxes, enter a secondary IP Address/Netmask.
6. Click Add.

How do I find my juniper interface IP address?

show interfaces (IP-over-IP)

1. Syntax. content_copy zoom_out_map.
2. Description. Display status information about the specified IP-over-IP interface.
3. Options. interface-type.
4. Required Privilege Level. view.

How do I reset my Juniper router?

To restart the switch from the front panel:

1. From the LCD front panel menu push the Menu button.
2. When the MAIN MENU (Maintenance menu) appears, press the Enter button.
3. Select the SYSTEM REBOOT option and press the Enter button.
4. To exit the menu without rebooting the switch, press the Menu button again.

How do I reset my juniper ssg5 password?

How To Recover Password Juniper SSG 550 Using Serial Number

1. Connect to the device with a console connection.
2. Log into the firewall using the device’s serial number as both the username and password.
3. A warning message will display, requesting confirmation to continue with the process.
4. A reconfirmation message displays.

How do I access my Juniper router?

To access a network device for the first time:

1. Connect a laptop or a desktop PC to the console port on the front panel of the device.
2. Power on the device and wait for it to boot.
3. Log in as the user root .
4. Type cli to start the Junos OS CLI.
5. Type configure to access CLI configuration mode.

What is Juniper router?

The Juniper MX-Series is a family of ethernet routers and switches designed and manufactured by Juniper Networks. In 2006, Juniper released the first of the MX-series, the MX960, MX240, and MX480. Utilizing the Juniper Extension Toolkit (JET), third party software can be integrated into the routers.

What is the juniper SSG 5 device?

The Juniper Networks Secure Services Gateway (SSG) 5 device is an integrated router and firewall platform that provides Internet Protocol Security (IPSec) virtual private network (VPN) and firewall services for a branch office or a retail outlet.

What is SSG 5 ISDN-WLAN?

„SSG 5 ISDN-WLAN All SSG 5 devices support a universal serial bus (USB) host module. The devices also provide protocol conversions between local area networks (LANs) and wide area networks (WANs), and three of the models support wireless local area networks (WLANs).

How to capture Ping attempts from SSG interfaces?

The interfaces are in route mode to avoid automatic nat. And the two policies do appear to allow the traffic from either direction. You can also try to capture the ping attempt using debug flow basic. This will outline all the packet processing on the SSG. Expand for debug flow steps.
